5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs
5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs 5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs 5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs 5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs

5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs

Product Details:
Place of Origin: China
Brand Name: BT
Certification: ISO9001
Model Number: BT-550D-5000A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 2500-3000 Set
Packaging Details: Wooden case
Delivery Time: 10 work days
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 200 set month
Contact Now
  • Detail Information
  • Product Description

Detail Information
Travel Of Welding Head: 40-140 Adjustable Display Interface: LCD Display
Parameter Panel: PVC Button Surface Mold Pre Welding Current: 800-2000A
Welding Time: 1-10ms Welding Current: 1000-10000A
Highlight:

LCD Lithium Battery Making Machine

,

Lithium Battery Making Machine 5000A

,

LCD Display DC Spot Welder

Product Description

LCD Display Lithium Battery Making Machine 5000A DC Spot Welder
Product Description
5000A DC Spot Welding Power Battery Spot Welder For Energy Storage Battery Pack
Introduction
The spot welding machine uses 5000A DC spot welding power source, which is used for the spot welding of nickel chip.
Key Features
  • The solder joint is beautiful, with minimal spark and no blackening. Welding current remains stable with even solder joint size.
  • Two welding pin pressure independent adjustment for stable and reliable welding pressure.
  • 2-year machine warranty with 24-hour technical support response for any failures.
  • Suitable for cylindrical, prismatic and polymer spot welding applications.
  • Robust construction with aesthetically pleasing design.
Technical Specifications
Model BT-550D-10000A
Application Cylindrical cells, prismatic cells, polymer cells
Power AC220 50/60Hz 2KW
Productivity 800-1200pcs/h
Spot Welding Power BT-10000A DC spot welding power
Welding Output Power Max 10000A
Air Pressure 0.4-0.8Mpa (No water, no impurities)
Spot Welding Pin 1.7mm (can use 1.5mm or 2mm depending on battery)
Nickel Sheet Thickness 0.1-0.3mm (slotted); 0.21-0.4mm (bump welding nickel sheet)
Spot Welding Platform L600*W300mm
Working Method Pneumatic
Travel of Welding Head 40-140mm (Adjustable)
Display Interface LCD Display
Parameter Panel PVC button surface mold
Pre Welding Current 800-10000A
Welding Time 1-10ms
Welding Current 1000-10000A
Dimensions L900*W900*H1350mm
Weight About 50kg
After-sales Service Overseas engineer support, video technical support, free spare parts, online support
Warranty 2 Years
Certification ISO9001, CE
5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs 0 5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs 1 5000A DC Lithium Battery Spot Welder with 10000A Max Output and 2 Years Warranty for Battery Packs 2
Frequently Asked Questions
Q: What types of machines can we make?
A: Our R&D equipment includes: Transistor spot welding power source, DC spot welding power source, automatic spot welding machine, dynamic performance tester of power cell, high-speed mat machine, 6-21 channel automatic sorting machine, Power Battery Performance Tester, power battery charge-discharge aging cabinet, CCD vision detector, automatic bracket machine, automatic battery production line, etc.
Q: Do you support after sales service?
A: Yes, we provide professional installation and training after purchase with a two-year warranty. We export to Europe, the United States, and Southeast Asian countries, with service sites in India.
Q: Is the quality of the product guaranteed?
A: As a high-tech enterprise established in 2005, we integrate R&D, production, and sales while maintaining a quality-first philosophy. Our cost-effective products have satisfied customers worldwide.
Q: What scope does the product apply to?
A: For 11 years, we've specialized in Battery Pack Automation Production Equipment and Production Lines, serving digital batteries, energy storage batteries, tool batteries, power batteries, and automotive batteries.
